DELTA

Description	DL	DC	AV	SP	Open Area%	SpFin	Steel kg/m²	Aluminium kg/m²	PanelSizesFe	PanelSizesAl
R 250x90(96)-25x1,5	250	90	25	1,5	59	37	6,3	2,1	DL 1000-1250-1500xDC 3000	DL 1000-1250-1500xDC 3000
R 250x90(96)-25x2	250	90	25	2	59	37	8,4	2,8	DL 1000-1250-1500xDC 3000	DL 1000-1250-1500xDC 3000
R 250x90(96)-25x3	250	90	25	3	59	37	12,6	4,2	DL 1000-1250-1500xDC 3000	DL 1000-1250-1500xDC 3000
