STADIUM




Description DL DC AV SP Open Area% SpFin Steel kg/m2 Aluminium kg/m2 PanelSizesFe PanelSizesAl
E 200x65(70)-20,6x1,52006520,61,556287,22,4DL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 maxDL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 max
E 200x65(70)-20,6x22006520,6256289,33,1DL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 maxDL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 max
E 200x65(70)-20,6x32006520,635628144,6DL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 maxDL 1000-1250-1500xDC 3000 | DL 2000-2500xDC 2500 max

Back | Download | Mesh real effect | Legenda
